ILS platform lift
ILS 1K
The ILS 1K is the larger platform lift from Innovation Lift Scandinavia, built in Sweden. It carries up to 1,000kg or eight persons, travels up to 13 metres and comes in platform sizes up to 1,400 x 2,500mm, including a 1,100 x 2,200mm stretcher size.
- Rated load
- 1,000kg, 8 persons
- Travel
- Up to 13m
- Pit
- 110mm
- Largest platform
- 1,400 x 2,500mm
Room for 1,000kg, eight persons or a stretcher
The ILS 1K is the larger platform lift from Innovation Lift Scandinavia, built in Sweden. It carries up to 1,000kg or eight persons and travels up to 13 metres, with platforms from 1,000 x 1,500mm up to 1,400 x 2,500mm.
Its standard sizes include a 1,100 x 2,200mm stretcher platform, alongside 1,400 x 2,000mm and 1,400 x 2,500mm platforms for larger groups and loads.
Built on the same drive as the ILS 05K
It uses a screw and nut drive with double monitored brakes and a 4kW motor, needs a 110mm pit and a minimum top height of 2,300mm, and takes steel swing doors on up to three sides, from 800 to 1,300mm wide.
The lift is operated with hold-to-run buttons that carry tactile and braille markings, battery emergency lowering is built in, and door operators, a level indicator and an emergency phone are available as options.
Key features
- Rated load of 1,000kg, for up to 8 persons
- Travel up to 13 metres at up to 0.15m/s
- Platforms from 1,000 x 1,500mm up to 1,400 x 2,500mm
- 1,100 x 2,200mm stretcher size platform
- 110mm pit and a minimum top height of 2,300mm
- Steel swing doors on up to three sides, 800 to 1,300mm wide
- Screw and nut drive with double monitored brakes
- Battery emergency lowering
- Hold-to-run buttons with tactile and braille markings
- Quiet, below 70dB(A)
- RAL 9003 white as standard, other RAL colours on request
- Door operators, a level indicator and an emergency phone available
- Built in Sweden
Specification
Figures from the product documentation. We confirm the exact specification for your building at survey.
- Outside size
- 1,530 x 2,280mm
- Rated load
- 1,000kg, 8 persons
Outside sizes are for doors at one end. The platform is drawn centred inside the outside size, and your survey fixes the exact layout.
- Type of lift
- Platform lift
- Manufacturer
- Innovation Lift Scandinavia, Sweden
- Rated load
- 1,000kg, 8 persons
- Rated speed
- Up to 0.15m/s
- Travel height
- Up to 13,000mm
- Pit
- 110mm
- Top height
- Minimum 2,300mm
- Drive system
- Screw and nut with double monitored brakes
- Motor
- 4kW
- Power supply
- 380 to 400V 3-phase 50/60Hz 16A
- Control
- PLC with soft start and stop
- Operation
- Hold-to-run buttons with tactile and braille markings
- Doors
- Steel swing doors on up to three sides, 800 to 1,300mm wide
- Emergency lowering
- Battery-powered
- Noise
- Below 70dB(A)
- Environment
- Indoor, +5°C to +40°C
- Usage
- 30 starts per hour
- Finish
- RAL 9003 white as standard, other RAL colours on request, glazing optional
- Options
- Door operators, level indicator, emergency phone, fold-down seat, chequer plate floor
- Technical compliance
- European Machinery Directive 2006/42/EC and European Standard EN 81-41:2010
Standard platform sizes
| Platform size | Outside size | Rated load |
|---|---|---|
| 1,100 x 2,200mm (stretcher) | 1,530 x 2,280mm | 1,000kg, 8 persons |
| 1,400 x 2,000mm | 1,830 x 2,080mm | 1,000kg, 8 persons |
| 1,400 x 2,500mm | 1,830 x 2,580mm | 1,000kg, 8 persons |
- Outside sizes are for doors at one end. Doors at both ends add 30mm to the depth, and a door on the side adds 30mm to the width.
- The cut-out in each floor is 30mm larger than the outside size each way.
- Other platform sizes are available in 100mm steps, from 1,000 x 1,500mm up to 1,400 x 2,500mm.
